Acoustics and piezoelectricity

The A1P facilities, localized in INSA Blois allow to perform vibrational measurements to determin the energy recovery of new piezoelectric materials. Equipment also allows to explore materials with acoustic microscopy, perform electrical and/or mechanical measurments on developing devices. The platform also performs ultrasonic non-destructive testing.

Scanning acoustic microscopy

Probe station
Signatone S1160 for samples up to 4”

Laser interferometer mounted on probe station
POLYTEC OFV-552 with : its controller POLYTEC OFV-5000 / POLYTEC OFV-072 Microscope Adapter / OLYMPUS SZX7 Zoom Stereo Microscope

Immersion characterization tanks
